FEATURES
Manufacture 3 ~ 40.6cc/rev single, tandem or triple pumps
High-strength extruded aluminum housing
Compact and light pump
Various combinations of abundant options – About 40 kinds

ㅡ ㅡ

SPECIFICATIONS
Typical Product Single Single Single Tendom Tendom
Max. Displacemant 4.5 cc/rev 12.3 cc/rev 6.5×10 cc/rev 14×7.2 cc/rev 22×14 cc/rev
Rated Pressure 17.6 Mpa (180kgf/㎠) 13.7 Mpa (140kgf/㎠) 17.6 Mpa (180kgf/㎠) 17.6 Mpa (180kgf/㎠) 17.6 Mpa (180kgf/㎠)
Max. Pressure 20.5 Mpa (210kgf/㎠) 16.7 Mpa (170kgf/㎠) 22.5 Mpa (230kgf/㎠) 22.5 Mpa (230kgf/㎠) 22.5 Mpa (230kgf/㎠)
Max. Speed for Self Priming 3,600 rpm 3,000 rpm 3,600 rpm 3,600 rpm 3,600 rpm
Working oiltemperature -25~80℃ -25~80℃ -25~80℃ -25~80℃ -25~80℃
